Shape Analysis are exclusive agents for [TC]2 in the UK for
scanners and software Sales
We have a [TC]2 NX-16 scanner available for demonstration.
If you are unable to travel to us, then we can arrange demonstrations of the
software and detailed description of the scanner at any location within the UK
and Europe.
We have a NX-16 scanner especially for demonstrations and renting. Please
contact us for more details.
NX-16 Scanner
We also have a secondhand NX-12 scanner available for purchase at a good
price if you can not afford a new NX-16 scanner.
Click here for the NX-12 Brochure
Applications
Made to Measure -
Brooks Brothers and
Benchmark Clothiers.
In conjunction with Benchmark, Shape Analysis intends to bring Made to Measure
clothing (Mens Suits to begin with) to the UK clothing market for off the peg
prices.
Size Surveys - SizeUK,
SizeUSA
Corporate Wear
Military and Civilian Uniforms
Body Armour Fitting
Medical
Fitness and weight loss or muscle gain tracking. We will shortly be rolling
out health club applications for our scanners -
Click Here for more details
[TC]˛ is a recognized world leader in body scanning. Their 3D Body Scanner
scans the whole human body in less than 6 seconds and produces a true-to-scale
3D body model within minutes. The uses of the 3D Body Model are unlimited,
including
 | Low cost, high quality, easy to use, and safe white light 3D body
scanning
White light is considered to be the safest body scanning technology. Laser
based scanning technologies (even at low power levels) have been rejected for
perceived safety issues. [TC]˛ scans are taken at floor level and
self-stabilizing hand-holds are provided for the scan subject. |
| Private self-scanning automated body scan acquisition
The [TC]˛ scanner is self-operated by the scan subject in a fully private
environment, without the need for a “scanner technician” to operate the
scanner. Audio streams provide instructions for the subject on where to stand
and what button to press. Manual operation is still an option if desired. |
| Auto-registration and accurate sensor head alignment
The [TC]˛ body scanner provides system sensor alignment calibration objects
and software with the system, and provides a cylinder object to allow the
customer to easily “check” to verify the views are aligned, and provide
feedback on the degree of alignment. The calibration process can be completed
in 15 minutes. |
| Body Scan Volume
The [TC]˛ scanner has one of the largest scan volumes available – scanning
objects over 2.1 meters tall and 1.2 meters wide. |
| Portability, Transportability, and Mobility
The ease of use and robustness of the [TC]˛ system is demonstrated in a four
day training program which allows the customer to disassemble, transport, and
re-assemble the scanning system on their own. After transport training, setup
from boxes only requires four hours. |
| Automatic creation of 3D body models from 3D body scan point cloud
data
3D scan data is very dense. The [TC]˛ Software has automatic noise
elimination, data filtering, data smoothing, hole filling, and data
compression as part of a process which automatically creates a high fidelity
segmented 3D model of the human subject. |
| Automatic body measurement extraction (numbering in the hundreds),
which can be user-customized for each apparel, garment, or equipment
application
[TC]˛ software automatically extracts “hundreds” of body measurements. It also
lets the user customize the measurement definitions to match their application
needs by using a simple wizard interface. |
| Automatic body shape and body volume extraction
Body shape and body volume extraction is fully automatic. |
| Internal joint location approximation for 18 major body joints |
| Seamless output data flow of measurements for made-to-measure
apparel CAD applications. Data output for 3D animation and engineering
packages.
[TC]˛ provides multiple data transfer options depending in the user needs –
whether it be for apparel CAD applications, animation or graphics
applications, and engineering CAD applications. [TC]˛ will support any
required data format specified by the customer as part of a scanner purchase.
Some to date include VRML, .ord, IGES, ASCII, direct export to Microsoft Excel
and many others. |
| Integrated Size Recommendation or Custom Fit functionality |
| Fully web enabled - direct data transfer from the scanner over
local networks or over the web |
